LCB5 Lubrication Unit
Motorized pump unit for the volumetric type system
Combines the LCB4 unit with an IC timer, preddure gauge and float switch
A 2L plastic or die-cast aluminum tank and a 4L extended plastic tank are available
Based upon the LCB4 lubrication unit, the LCB5 are equipped with an IC timer (control board), a pressure switch, a float switch an Instant discharge button and an option to select a 4L extended plastic tank and / pressure gauge.
The intermittence time between discharges can be adjusted from a range of 2～180 minutes by simply altering the dip switch settings on the timer.
Form code
Specifications
| MODEL CODE | Intermittence (Rest time in mins.) | Discharge Vol. (L / minute) | Discharge Pressure | Tank Capacity (L) | Effective Tank Capacity (L) | Viscosity Range | Warning Triggers |
| LCB50 | 2, 4, 6, 8, 10, 15, 20, 25, 30, 40, 50, 60, 90, 120, 150, 180 | 0.1L / 0.12L 50Hz / 60Hz | 1.2MPa | 2 | 1.3 | 50～800 m㎡/s | Pressure surge, pressure loss, low oil levels |
| LCB51 | 2 | 1.3 | |||||
| LCB52 | 4 | 1.9 |
※Lubricant can be discharged by pressing the “Instant button”. The pump will continue to operate until the button is released.
Drawing
